IP37C43 1/2.9" SSC337 Security CCTV HD Camera Module board 4MP H.264 H.265

SKU: IP37C43

Video Coding:

H.264, H.265+

Hole Distance:

20mm

Resolution:

$17.50

Weight: 0.05 kg

Description

Technical Characteristics:
1. Support 2 channels of video and 1 channel of audio, two channels independent, 30 frames per second active video (4MP)
2. H.264/H.265/H.265+ video compression standard, G.711 audio compression standard

3. Embedded Web Server, fully support Internet Explore monitoring, configuration, and upgrade
4. Two-way audio real-time transmission on the Internet, the video frame rate is automatically adjusted according to the bandwidth
5. Support variable bit rate, while setting the video image quality, it can also limit the video image compression code stream
6. Support DHCP, easy to realize dynamic IP address
7. Video bit rate 64Kbps-3Mbps continuously adjustable, frame rate (5-30) continuously adjustable
8. Support JPEG capture
9. Support movement detection (settable area and sensitivity) and input and output alarm
10. 10/100M Ethernet interface support
11. Support up to 5 users to access at the same time
12. Support sound linkage alarm and voice customization
13. Support regular maintenance function
14. Support IP filtering
15. Support OSD customization
16. Support client remote monitoring software
17. Support mobile phone monitoring (P2P)
18. Support Safari, Chrome, FireFox, Opera, Edge browser
19. Support soft photosensitive infrared, ordinary infrared
20. Support auto focus and PTZ

model	IP37C43
SOC	SigmaStar SSC337
Image sensor	1/2.9" 4MP
Minimum illumination	Color 0.01 Lux
SNR	>=50dB
Video processing	PAL/NTSC video standard chooseable, support AWB, support 3D DNR, support WDR, support anti-face overexposing, support defog, H.264/H.265/H.265+ coding format, achieve ultra-low storage, code rate/frame rate adjustable, manual adjustable shutter
Image resolution	Main stream: 5MP@25fps, 4MP@25fps, 3MP@25fps, 1080P/720P/D1@30fps sub stream: D1 / VGA / 640*360 / CIF @30fps support CBR/VBR
Audio processing	Audio linear input/output, G711u/G711A encoding, support two-way voice intercom
Network interface	RJ45, 10/100Mbps adaptive Ethernet interface, 2KV lightning protection
Protocol support	Support HTTP/RTSP/ DHCP/NTP/ONVIF/P2P network protocols, and GB28181, RTMP and many kinds of NVR protocols are optional
storage	Not available
IO interface	Supports electric zoom and auto focus interface, with zoom lens and zoom control board and zoom program
LED Board interface	Support active mode and passive mode, need compatible light board to work together
IRCUT interface	Integrated IRCUT filters switching circuit, Auto / external / manual / timer to control IRCUT day/night mode
Business functions	IE6.0 and above (device embedded Web Server) browser mobile detection and OSD adjustable JPEG screenshots P2P cloud services (danale) IP filters provide the SDK (Windows, Android, Linux) development kit Active infrared function Active warm light function automatic zoom (optional) PTZ linkage support voice alarm linkage and customizable alarm sound
Conventional parameters	DC12V/POE (Optional), 38 (L) *38 (W) (without lens), 0.06kg
Working temperature	-30~70 ℃

Please contact us for more info.

Pin Definition

Single Board H.265 Full function

No.	Pin Defination	Pitch	Preview
JP4 Power interface		1.25mm
1	DC12V
2	Video GND
3	CVBS Signal Out
4	GND
J6 Network interface		1.25mm
1	RJ45_1 (TX+)
2	RJ45_2 (TX-)
3	RJ45_3 (RX+)
4	RJ45_6 (RX-)
5	Network connector light(Green)
6	Network status light(Yellow)
J1 IR-cut interface		1.25mm
1	IR-CUT control signal 12V-
2	IR-CUT control signal 12V+
J3 LED Board interface		1.25mm
1	LED board 12V power out
2	GND
3	LED feedback signal (0.8V-12V)
4	Infrared light enable control
J2 Function interface		1.25mm
1	Audio in
2	Audio GND
3	Audio out
4	Reset
5	GND
6	USB_DP
7	USB_DM
8	5V power out
9	alarm out I/O(3.3V Level signal)
10	Alarm in
